How to Fix WiFi Not Working on a Canon Printer: WPS, IJ Network Device Setup Utility, and Manual TCP/IP Fixes

Canon PIXMA and MAXIFY printers are reliable workhorses, but their wireless setup can trip you up if you hit the wrong combination of router settings, band configuration, or stale network credentials. Unlike a laptop or phone, a printer gives you almost no feedback when the connection fails — you just get a blinking orange light or a vague “Cannot Connect” error on screen. This guide walks through every effective fix in order of simplicity.

Fix 1: Confirm Your Router Is Broadcasting 2.4 GHz

This is the single most common cause of Canon printer connection failures, and the easiest to overlook. Every current Canon PIXMA and MAXIFY model supports only the 2.4 GHz band. If your router broadcasts both bands under the same SSID (network name) and has steered your printer toward 5 GHz, the printer simply cannot associate — it will attempt the connection and silently fail.

Log into your router’s admin panel (usually at 192.168.1.1 or 192.168.0.1) and confirm that 2.4 GHz is enabled. If your router uses band steering or merges both bands under one SSID, create a separate 2.4 GHz-only SSID and connect the printer to that. Our guide on 2.4 GHz vs 5 GHz vs 6 GHz explains the tradeoffs in detail.

Also confirm that the SSID does not use special characters like apostrophes, slashes, or emoji. Canon firmware has known compatibility issues with non-alphanumeric SSID names. A plain name like HomeNetwork_2G is the safest choice.

Fix 2: Use WPS for a Password-Free Connection

WPS (Wi-Fi Protected Setup) is the fastest way to connect a Canon printer without typing a password. It works on most home routers manufactured after 2010, and Canon’s implementation is reliable on current hardware.

1. On the printer’s control panel, navigate to LAN Settings → Wireless LAN Setup → WPS (Push Button Method). The exact path varies slightly by model — on touchscreen models like the PIXMA TR series, it’s under Settings → LAN Settings → Wi-Fi → Wi-Fi Setup → Push Button Method (WPS).
2. Press OK or Connect on the printer. You have approximately two minutes to complete the next step.
3. Press and hold the WPS button on your router for two to three seconds until its WPS indicator starts blinking.
4. Wait up to 90 seconds. The printer’s Wi-Fi indicator will turn solid blue when the connection is established.

If WPS fails, your router may have WPS disabled (a common security hardening step) or the two-minute window may have expired. Move on to Fix 3 in that case.

Fix 3: Re-Run Wireless Setup with the Correct Password

Stale or mis-typed network credentials are a frequent culprit — especially after a router replacement or ISP-forced password change. The printer stores the old credentials and keeps attempting the old connection without informing you clearly.

Reset the printer’s network settings first: on most Canon models, go to Settings → Device Settings → Reset Settings → LAN Settings (or Reset LAN Settings on non-touchscreen models — hold Stop for five seconds). This clears stored SSIDs and passwords without affecting printer settings.

Then restart the wireless setup wizard from the printer’s control panel: LAN Settings → Wireless LAN Setup → Standard Setup. Select your 2.4 GHz SSID from the list and enter the password character by character. Watch for case sensitivity — Canon’s on-screen keyboard defaults to uppercase; toggle case before entering lowercase characters.

Fix 4: Use the IJ Network Device Setup Utility

Canon’s IJ Network Device Setup Utility is a free Windows and macOS application that can detect Canon printers on your network, diagnose connection problems, and update network settings directly — even if the printer has an IP address conflict or incorrect subnet configuration. It’s the most powerful troubleshooting tool available for Canon wireless printers.

1. Download the IJ Network Device Setup Utility from Canon’s official support site (search “IJ Network Device Setup Utility” on support.usa.canon.com).
2. Connect the printer to your computer with a USB cable temporarily.
3. Launch the utility. It will detect the printer via USB and display its current network status, including the SSID it’s associated with, signal strength, IP address, and any error codes.
4. Click Wireless LAN Setup and follow the guided wizard. The utility can update the printer’s SSID and password directly, eliminating the need to navigate the printer’s own control panel menus.
5. Once setup is complete, disconnect the USB cable. The printer will reconnect wirelessly.

The utility also lets you print a Network Settings Report from the printer (hold the Wi-Fi button for three seconds on most PIXMA models) — a diagnostic page that shows the current IP, SSID, signal level (in dBm), and connection status. See our guide on WiFi signal strength and dBm values to interpret the signal reading.

Fix 5: Assign a Static IP via Manual TCP/IP Configuration

If the printer connects successfully but disappears from the network after a router reboot — or if print jobs stall because the printer’s IP address changes via DHCP — assigning a static IP address solves the problem permanently.

There are two ways to do this:

Option A: Reserve the IP on the Router (Recommended)

Log into your router’s admin panel, navigate to the DHCP reservation or static lease section, and bind the printer’s MAC address (visible on the Network Settings Report or the IJ Network Device Setup Utility) to a specific IP address, such as 192.168.1.200. The router will always assign that IP to the printer, and you don’t need to touch the printer’s settings.

Option B: Set a Static IP on the Printer

On the printer, go to LAN Settings → Wi-Fi → Advanced → TCP/IP Settings and switch from Auto to Manual. Enter an IP address outside your router’s DHCP range (for example, if DHCP assigns 192.168.1.2–192.168.1.100, use 192.168.1.150), and set the subnet mask to 255.255.255.0 and the default gateway to your router’s IP (usually 192.168.1.1). Set the DNS server to 8.8.8.8 (Google) or 1.1.1.1 (Cloudflare). Save and restart the printer.

Fix 6: Check for Firmware and Driver Updates

Canon periodically releases firmware updates that address wireless stability issues. On touchscreen PIXMA models, check for updates at Settings → Web Service Setup → Web Service Connection Setup → Firmware Update. Alternatively, use the Canon PRINT Inkjet/SELPHY app on a smartphone connected to the same WiFi network to check for and apply updates.

On the computer side, reinstalling the latest drivers from Canon’s support site can resolve issues where the printer is detected on the network but jobs don’t print. Stale printer drivers sometimes cache an old IP address and refuse to redirect to the new one.

Quick Checklist

1. Confirm router is broadcasting 2.4 GHz and the SSID is visible to other devices.
2. Try WPS if your router supports it — press the router button within two minutes of starting WPS on the printer.
3. Reset LAN settings on the printer and re-enter credentials carefully, checking case.
4. Run the IJ Network Device Setup Utility via USB to diagnose and reconfigure wirelessly.
5. Assign a static IP via DHCP reservation on the router to prevent future address changes.
6. Update printer firmware and reinstall drivers on the PC or Mac.

Most Canon WiFi failures resolve at Fix 1 or Fix 3. If you’re still stuck after all six fixes, the printer’s wireless card may be faulty — Canon’s support line can arrange a depot repair for units under warranty. For broader WiFi troubleshooting across your home network, see our guide on WiFi connected but no internet and our comparison of WiFi extender options if coverage near your printer is weak.
